| Chipset |
Intel 865PE + ICH5 |
| Processor |
- Socket 478 on board.
- Supporting P4 CPU
(including Prescott CPU and
Hyper Threading Technology).
|
| Front Side Bus |
800/533/400MHz Front Side Bus. |
| Memory |
- 2 x 184-pin DDR DIMM Sockets.
- Supporting unregistered non-ECC DDR 400/333/266 DRAM up to 2GB.
- Supporting Dual-Channel.
|
| Expansion Slots |
- 1 x AGP 8X/4X Slot.
- 5 x PCI Slots.
|
| On-Board EIDE |
2 x ATA100/66/33 IDE connectors supporting up to 4 IDE devices. |
| On-Board SATA |
2 x Serial ATA connectors supporting 2 Serial ATA HDDs. |
| |
|
| Integrated Super I/O |
- 1 x Floppy Port.
- 1 x PS/2 Mouse Port.
- 1 x PS/2 Keyboard Port.
- 1 x Gigabit LAN Port.
- 1 x Parallel Port.
- 2 x Serial Ports.
- 8 x USB 2.0/1.1 Ports. (4 integrated, 4 via
optional cables)
- Audio Ports.
|
| RAID |
|
| IEEE1394 |
|
| Audio |
6-Channel AC'97 Audio. |
| LAN |
Gigabit LAN Function. |
| BIOS |
- AMI BIOS.
- Flash Memory for easy upgrade.
|
| Form Factor |
ATX Form Factor (305mm x 210mm) |
| Other Features |
- BIOS FSB Setting.
- BIOS Writing Protection.
- BIOS AGP, DIMM, Vcore Voltage Setting.
- BIOS Multiplier Setting.
- SmartDoc. Anti-burning Shield. (optional)
- RedStorm Overclocking Technology. (optional)
- Soltek H/M Monitor.
- STR Function. (optional)
|
