| Chipset |
Intel 865PE + ICH5 |
| Processor |
- Socket 478 on board.
- Supporting P4 CPU
(including Prescott CPU and
Hyper Threading Technology).
|
| Front Side Bus |
800/533/400MHz Front Side Bus. |
| Memory |
- 4 x 184-pin DDR DIMM Sockets.
- Supporting unregistered non-ECC DDR 400/333/266 DRAM up to 4GB.
- Supporting Dual-Channel.
|
| Expansion Slots |
- 1 x AGP 8X/4X Slot.
- 6 x PCI Slots.
|
| On-Board EIDE |
- 2 x ATA100/66/33 IDE connectors supporting up to 4 IDE devices.
- 1 x ATA 133/RAID IDE connector supporting up to 2 IDE devices by Promise
PDC20378.
|
| On-Board SATA |
- 2 x Serial ATA connectors supporting 2 Serial ATA HDDs. (by ICH5)
- 2 x Serial ATA connectors supporting 2 Serial ATA HDDs. (by Promise PDC20378)
|
| |
|
| Integrated Super I/O |
- 1 x Floppy Port.
- 1 x PS/2 Mouse Port.
- 1 x PS/2 Keyboard Port.
- 1 x Gigabit LAN Port. (For SL-865-GR only)
- 1 x Parallel Port.
- 2 x Serial Ports.
- 8 x USB 2.0/1.1 Ports. (4 integrated, 4 via
optional cables)
- Audio Ports.
|
| RAID |
2 x Serial ATA connectors and 1 x ATA133/RAID IDE Port supported by Promise
PDC20378. (RAID0, 1, 0+1) |
| IEEE1394 |
|
| Audio |
6-Channel AC'97 Audio. |
| LAN |
Gigabit 10/100/1000 LAN Function. (For SL-865-GR only) |
| BIOS |
- AMI BIOS.
- Flash Memory for easy upgrade.
|
| Form Factor |
ATX Form Factor (305mm x 244mm) |
| Other Features |
- BIOS FSB Setting.
- BIOS Writing Protection.
- BIOS AGP, DIMM, Vcore Voltage Setting.
- BIOS Multiplier Setting.
- SmartDoc. Anti-burning Shield. (optional)
- RedStorm Overclocking Technology. (optional)
- Soltek H/M Monitor.
- STR Function. (optional)
|
