| Chipset |
Intel 855GME + ICH4 |
| Processor |
- Socket 479 on board.
- Supporting Pentium M / Celeron M CPUs
|
| Front Side Bus |
400MHz Front Side Bus. |
| Memory |
- 2 x 184-pin DDR DIMM Sockets.
- Supporting unregistered ECC/non-ECC DDR 333/266 DRAM up to 2GB
|
| Expansion Slots |
- 1 x AGP 4X Slot.
- 3 x PCI Slots.
|
| On-Board EIDE |
2 x ATA100/66/33 IDE connectors supporting up to 4 IDE devices. |
| On-Board SATA |
2 x Serial ATA connectors supporting 2 Serial ATA devices.
(by Promise PDC20579) |
| |
|
| Integrated Super I/O |
- 1 x Floppy Port.
- 1 x PS/2 Mouse Port.
- 1 x PS/2 Keyboard Port.
- 2 x Gigabit LAN Ports.
- 1 x Parallel Port. (via optional
cable)
- 2 x Serial Ports. (1 integrated, 1 via optional
cable)
- 6 x USB 2.0/1.1 Ports. (4 integrated, 2 via
optional cables)
- Audio Ports.
- 2 x IEEE1394 Ports. (2 via optional
cables)
- 1 x VGA Port.
- 1 x S/PDIF In Port.
- 1 x S/PDIF Out Port.
|
| RAID |
2 x Serial ATA connectors supported by Promise PDC20579. (RAID0, 1) |
| IEEE1394 |
2 x IEEE1394a Ports. (2 via optional
cables) |
| Audio |
8-Channel AC'97 Audio |
| LAN |
Dual-Gigabit 10/100/1000 LAN Function |
| BIOS |
- Award BIOS.
- Flash Memory for easy upgrade.
|
| Form Factor |
Micro ATX Form Factor(245mm x 245mm) |
| Other Features |
- BIOS Writing Protection.
- BIOS AGP, DIMM Voltage Setting.
- SmartDoc. Anti-burning Shield. (optional)
- RedStorm2 Overclocking Technology. (optional)
- Soltek H/W Monitor.
- STR Function.
|
