| Chipset |
VIA VT82C694T + VT82C686B |
| Processor |
CPU Socket 370 on board. |
| Front Side Bus |
133/100/66 MHz Front Side Bus. |
| Memory |
- 3 x 168-pin SDRAM DIMM Sockets.
- 3 DIMMs or 6 banks at 133 MHz for 1.5 GB max memory.
- 133/100/66MHz system memory bus frequency
|
| Expansion Slots |
- 1 x AGP 4X Slot.
- 5 x PCI Slots. (32-bit)
- 1 x ISA Slot. (16-bit)
- 1 x AMR (Audio Modem Riser) Slot.
|
| On-Board EIDE |
2 x ATA100/66/33 IDE connectors supporting up to 4 IDE devices. |
| On-Board SATA |
|
| |
|
| Integrated Super I/O |
- 1 x Floppy Port.
- 1 x PS/2 Mouse Port.
- 1 x PS/2 Keyboard Port.
- 1 x Parallel Port.
- 2 x Serial Ports.
- 4 x USB 1.1 Ports. (2 integrated, 2 via optional
cables)
- 1 x Audio/Game Port
|
| RAID |
|
| IEEE1394 |
|
| Audio |
2-Channel AC'97 Audio. |
| LAN |
|
| BIOS |
- Award BIOS.
- Supports Advanced Power Management Function.
- Flash Memory for easy upgrade
|
| Form Factor |
ATX Form Factor (190mm x 305mm) |
| Other Features |
- BIOS FSB Setting.
- BIOS Writing Protection.
- Ultra ATA 33/66/100.
- H/W Monitor.
- AC'97 Audio Function.
- AMR (Audio Modem Riser) Interface.
|
