| Chipset |
Intel 815EP B-Step |
| Processor |
CPU Socket 370 on board. |
| Front Side Bus |
133/100/66MHz Front Side Bus. |
| Memory |
- 3 x 168-pin DIMM Sockets.
- 6 banks DRAMs supported up to 1GB (256Mb DRAM technology) (maximum) memory
space.
|
| Expansion Slots |
- 1 x AGP 4X Slot.
- 5 x PCI Slots.
- 1 x CNR Slot.
|
| On-Board EIDE |
2 x ATA100/66/33 IDE connectors supporting up to 4 IDE devices. |
| On-Board SATA |
|
| |
|
| Integrated Super I/O |
- 1 x Floppy Port.
- 1 x PS/2 Mouse Port.
- 1 x PS/2 Keyboard Port.
- 1 x Parallel Port.
- 2 x Serial Ports.
- 4 x USB 1.1 Ports. (2 integrated, 2 via optional
cables)
- Audio/Game Ports.
|
| RAID |
|
| IEEE1394 |
|
| Audio |
2-Channel AC'97 Audio. |
| LAN |
|
| BIOS |
- Award BIOS.
- Flash Memory for easy upgrade.
|
| Form Factor |
ATX Form Factor (200mm x 305mm) |
| Other Features |
- BIOS FSB Setting.
- BIOS Writing Protection.
- SmartDoc. Anti-burning Shield. (optional)
- RedStorm Overclocking Technology. (optional)
- H/M Monitor.
- SCR (Smart Card Reader) Function. (optional)
|
